 | Product Name | Microfiber Cleanroom Wiper |
| Weight | 230gsm+/-3gsm |
| Edge cutting | Laser / Ultrasonic Cutting |
| Material | 30% Chinlon+70% Polyester |
| Grain | Straight line double knitted |
| Class | 1000-10 |
| Package way | Vacuum |
| Size | 12"*12",9"*9",6"*6",4"*4" |
Description
Microfiber Knit wipes are made with fabric densely knitted by continuous micro denier filament. The unique structure of microfiber improves the surface contact, and provides more effective cleaning.
Applications
• Wiping and cleaning surfaces, equipment and parts.
• Applying and removing lubricants, adhesives, residues and other solutions including disinfectants.
• Cleaning with solvents such as isopropyl alcohol (IPA), ethanol, acetone, and degreasers.
Features and Benefits
• Cleanroom laundered and packaged providing ultra low levels of ions and non volatile residues.
• Designed for use on abrasive surfaces. This wipe will not easily snag or abrade releasing articles and fibers into the process or environment.
• Excellent chemical resistance for compatibility with a variety of solutions.
• Individually lot coded for ease of trace-ability and quality control.
• Good absorption with water and solvents.Hold more dirt and residues than average wipe. Remove residues from the surface more effectively.
Technical Data
• Wipe material 100% Polyester
| Attribute; (units) | Value | Test Method |
| Basis weight; nominal (g/m2) | 228 | MSD-QI-QS-007 A0 |
| Absorbency in water |
| IEST-RP-CC004.3 |
| Intrinsic; (mL/g) | 1.62 |
|
| Extrinsic; (mL/m2) | 369.36 |
|
| Sorptive rate; (seconds) | 1 | IEST-RP-CC004.3 |
| Non-volatile residue, NVR |
| IEST-RP-CC004.3 |
| In deionized water; (g/m2) | 0.01 |
|
| In isopropanol; (g/m2) | 0.03 |
|
| Specific ions |
| IEST-RP-CC004.3 |
| Sodium; (ppm) |
|
|
| Chloride; (ppm) | 0.008 |
|
| Potassium; (ppm) | 0.065 |
|
| Particles, readily releasable | 0.082 |
|
| APC: ≥0.3μm(Ea/ft3) | 49 | IEST-RP-CC003.3 |
| LPC:≥0.5μm(106/m2 ) | 18 | IEST-RP-CC004.3 |
Cleanroom Environment
• ISO Class 3 – 8
• Class 1 – 100,000
Shelf Life
• Non-Sterile (Dry) – 3 years from date of manufacture
• Non-Sterile (Pre-Wetted) – 2 years from the date of manufacture
• Sterile – 2 years from the date of manufacture
